CERTOFIX TRIO 720-EU/SA | B. Braun4163206E-07CERTOFIX TRIO 720-EU/SA
- Nazwa marki
- Certofix®
- Product name (HC)
- Certofix® Trio
- Rozszerzonyrodzaj produktu
- Central venous catheter
- Introduction technology
- Seldinger
- Venous access site
- jugularis, subclavia, axillary
- Material of catheter
- PUR
- Number of lumen
- 3
- Skala French F (cewnik)
- 7.0 Fg
- Długość cewnika
- 20 cm
- Długość (cale)
- 8"
- Zewnętrzne-ø cewnika (skala me
- 2.40 mm
- Długość prowadnika
- 50.0 cm
- Outer-ø of guidewire
- 0.890 mm
- with kink proofed guide wire
- Yes
- Grubość (dystalna)
- 16
- Priming volume (distal)
- 0.38 ml
- Flow rate (distal)
- 46 ml/min
- Gauge (medial 1)
- 18
- Priming volume (medial 1)
- 0.32 ml
- Flow rate (medial 1)
- 22 ml/min
- Gauge (medial 2)
- -
- Gauge (medial 3)
- -
- Gauge (proximal)
- 18
- Priming volume (proximal)
- 0.30 ml
- Flow rate (proximal)
- 22 ml/min
- Type of cannula
- Seldinger
- Gauge (Cannula)
- 18
- Outer-ø cannula (mm)
- 1.30 mm
- Length of cannula (mm)
- 70 mm
- Length of cannula (inch)
- 2 3/4"
- Outer-ø tube
- 1.95 mm
- Inner-ø tube
- 1.40 mm
- Długość rurki
- 121.50 mm
- ECG-Cables
- No
- enclosed Connector
- IN-Stopper
- incl. scalpel
- No
- with syringe
- No
- Type of packaging
- Peel pack
- Produktu (rozpakowany) zawiera
- No
- Produktu (rozpakowany) zawiera
- No
- Produktu (rozpakowany) zawiera
- No
- Rodzaj Sterylizacji (dopuszcza
- No
- Produkt zawiera Latex
- No
- Rodzaj Sterylizacji (dopuszcza
- No
- Produktu (rozpakowany) zawiera
- No
- Rodzaj Sterylizacji (dopuszcza
- No
- Product contains Nickel
- Yes
- Jednorazowy / wielorazowy
- jednorazowego użytku
- Sterylność
- sterylne
- Rodzaj sterylizacji
- EO
- Antimicrobial Catheter
- non-coated
- High Flow Sets
- No
- Safety Sets
- No
- Paed Sets
- No
