DiaStream Ecoprime V | B. BraunBLU009BDiaStream Ecoprime V
- Rozszerzonyrodzaj produktu
- A/V Sets
- Applicable machine
- B.Braun - Dialog Advanced, B.Braun - Dialog +, B.Braun - Dialog
- Features
- 3 ways stopcock, Color code clamps, A exp. chamber, Spike, Drain Bag 2000 ml, 3 combi stopper, 3 transducer protectors
- Capacity drain bag
- 2 l
- Objętość napełniania
- 159 ml
- Arterial volume
- 86 ml
- Venous volume
- 74 ml
- Inner-ø Pump segment
- 8.00 mm
- Inner-ø Bloodline tubing
- 4,3/4,8 mm
- Inner-ø Heparine line
- 1.00 mm
- ø Venous chamber
- 22 mm
- Rodzaj Sterylizacji (dopuszcza
- Yes
- Produkt zawiera Latex
- No
- Rodzaj Sterylizacji (dopuszcza
- No
- Sterylność
- sterylne
- Rodzaj sterylizacji
- Beta
- Jednorazowy / wielorazowy
- jednorazowego użytku
- Storage Environment Temperatur
- 0 °C - 40 °C
- Storage Environment Humidity
- 0 % - 80 %
